Find your LED videowall in 4 steps

From a photo of your wall to a custom configuration — our advisor helps you choose the right pitch, LED type and controller for the application.

⚠ Gratis configuratietool. Vraag een vrijblijvende offerte aan via het formulier hieronder.

Which controller do I need?

A GEN5 controller receives signal sources (HDMI, DisplayPort, SDI, IP streaming) and distributes the pixels over the cabinets of your wall. The series you pick depends on how many sources you need, how large your wall is, and whether you need advanced scaling/windowing.

C-series Compact · Budget

Plug-and-play controller for one simple source.

2 output channels → max ~2.6M pixels (e.g. 4K UHD 3840×2160)
1 main source (HDMI), picture-in-picture optional
No advanced scaling, no multi-windowing
Perfect for: signage, lobby, small meeting rooms, single PPT

2 chmax pixels: ~2.6M

P-series Processor · Mid

Full video processor with multi-window & scaling.

6 output channels → max ~7.9M pixels
Multiple sources (HDMI, DP, SDI) simultaneously
PiP, PoP, window splitting, scaling, HDR10
Perfect for: boardrooms, control rooms, broadcast sources

6 chmax pixels: ~7.9M

V-series Video · Premium

High-end processor for large walls and complex source setups.

20 output channels → max ~13M pixels (8K ready)
Up to 8 simultaneous sources, 16 independent windows
Genlock sync, EDID management, backup switching
Perfect for: XR studios, large signage, auditoria, cinema

20 chmax pixels: ~13M

C-series · simple single-source flow

One source (a PC or media player) goes directly into the C-controller. The controller splits the image over the cabinets via 2 LAN output channels. Ideal when you just want to show one thing.

V/P-series · multi-source with window splitting

Multiple sources — for example a camera feed, a PowerPoint and a dashboard — come into the V/P processor. The processor arranges them in windows (PiP/PoP), scales them and distributes the pixels over up to 20 LAN output channels. Each channel feeds a group of cabinets.

Rule of thumb: if you have ONE source and a smaller wall (< 2.6M pixels), C-series is perfect. Do you have multiple sources, need PiP/PoP, or a larger wall? Then go for P-series. Large walls (> 8M pixels), broadcast/XR studio, or 8+ simultaneous sources? Then V-series is the answer.

1Photo of the wall optional — helps visualize scale

📁

Upload photo

JPG / PNG — from laptop or desktop

📷

Take photo

Uses camera on phone or tablet

Wall width (m)

Wall height (m)

View mode

— cabinets

Flat (rectified) view — the photo is warped so the wall is a true rectangle.

How it works: Step 1 — drag the 4 orange markers (TL / TR / BR / BL) so they snap exactly to the wall corners in the photo (not the screen!). Step 2 — drag the green handles on the screen to resize it. The cabinet grid and count update live as you drag. Switch to Flat view to see the wall warped into a true rectangle.

🖼 Content preview

📐

Wall corners = where your wall meets the floor, ceiling and side walls — not where you want the screen. The calibration uses your wandbreedte (5.00 m) and wandhoogte (2.70 m) as reference.

Screen width (m)

Screen height (m)

Or diagonal (inch)

2Where will the screen be installed?

AWhat is the application?

👥Meeting roomoffice 💼Boardroomexecutive 🖥️Control roommonitoring 🎤Auditoriumlecture / stage 🎬Studiobroadcast 🛍️Retailshowroom / shop 📢Signagelobby / entrance 🎥Cinemaevent / theater

BHow close are viewers typically standing?

🔍Close< 2 m 👀Medium2 – 4 m 🏛️Far4 – 6 m 🔭Very far> 6 m

CWhat will be shown on screen most of the time?

🎞️Video / imagelow detail 📊PresentationsPowerPoint 📈Data / Excelhigh detail 📐CAD / drawingsvery high detail

Our recommendation

—

3Configuration

Number of cabinets (columns × rows, 600×337.5 mm)

LED type

SMDbudget

HOBstrong

COBpremium

Pixel pitch

Controller advisor

Beantwoord de vragen om de juiste controller te bepalen.

Hoeveel HDMI/DP-inputs heb je nodig? Wil je draadloos je laptop scherm delen?

Nee Ja, draadloosvereist P-serie + dongle

Wil je een ingebouwde signage player (Focsign)?

Nee Ja, Focsignvereist P-serie

Optionele accessoires Wireless Dongle DS-D5SC3B-B — alleen met P-serie
Lichtsensor + Multi-function Card DS-D42A05 + DS-D42AM2-N

Montageframe / beugel

⚠ Het montageframe is geen onderdeel van onze levering.
Montageframes zijn altijd maatwerk en worden verzorgd door een partner (bijv. Vogel's dvLED Connect-it).
Wij geven advies over de juiste bevestiging. Neem contact op voor een offerte op maat.

Screen preview (to scale)

3bVogel's dvLED Connect-it — montage-oplossing

Auto-configurator voor Vogel's-beugels. Op basis van je keuzes in stap 3 berekenen we onderdelen, gereedschap en montagestappen. Montageframes zijn partner-werk (Vogel's dvLED Connect-it) — deze specificatie is indicatief voor offerte-aanvraag.

Opties bij de beugel-offerte Gereedschapsset Vogel's service-tool, digitale waterpas, momentsleutel Kabelmanagement-kit geleiders + klittenband-strips Service-spares (10%) reserve cabinet-adapters voor later onderhoud

⚠ Indicatief: Vogel's part-nummers en aantallen zijn indicatief op basis van het Vogel's Connect-it-systeem. Exacte SKU's verifiëren via Vogel's-distributeur bij bestelling.

4Your configuration

Dimensions

— m

Surface area

— m²

Resolution

— px

Total pixels

—

Cabinets

—

Weight

— kg

Max power

— W

Avg. power

— W

Volgende stap

Vraag een vrijblijvende offerte aan via het formulier hieronder

Vraag een vrijblijvende offerte aan via het formulier hieronder voor een volledige opgave, inclusief installatie en transport.

5Vraag uw persoonlijke offerte aan

Leave your details and we will send you a formal quotation based on your configuration. You will receive a confirmation email within minutes.

Your details

Full name *

Company

Quote reference

Email address *

Phone

Street & number

Postal code & city

Installation & location

How will the screen be mounted?

Installation environment

Installation performed by

Desired installation date

Audio & unified communications

Audio requirements

Video conferencing / UC

Extra equipment (check what applies)

PTZ camera Ceiling / table mic Touch overlay Signage media player Scheduled on/off Control panel (Crestron/Q-Sys) Live streaming input Redundant power/signal

Technical & site conditions

Available power supply

Network connection

Primary signal source(s)

Budget range (optional)

Anything else we should know?

Ik ga ermee akkoord dat SelPix contact met mij opneemt over deze aanvraag en mijn gegevens bewaart conform de privacyverklaring. *

✓

Thank you, your request has been received

Reference: —

A confirmation email is on its way to you. Our team will review your configuration and reach out within one business day with a formal quotation.

Laat mij de configuratie zien →

Technical data: Hikvision GEN5 brochure Mar. 2025
